operation has been investigated and a decrease in the amount of perlite from 35 to
30% has been proved. The surface of the anode after 20.5 years of operation is
subjected to general and peptic corrosion, the depth of ulcers will be up to 1 mm
outside the pipe and up to 0.7 mm on the inner surface. It is confirmed that
hardness of metal is not a value sensitive to operational degradation.
Electrochemical studies have shown that the resistance of the soil and the
resistance of anode grounding from steel 20, after a long period of operation, is
gradually increasing. It is established that the potential of corrosion and the anode
current of dissolving steel 20 of the stock tube and the anode practically coincide.
However, the exploited steel is inherent in a slightly higher intensity of anode
dissolution in the potential of -0.40 V, this indicates the advantage of the use of
anodes from pre-exploited pipes against the reservoir tubes due to economic and
functional expediency.
The study of the characteristics of the anode grounds of steel 12Х18Н10Т,
which showed that in 2.5 years of operation, the metal structure has not changed
and satisfies the current requirements of GOST 550-75. An increase in the strength
of the anode grounds of steel 12Х18Н10Т is shown by 3–8% and not significant
corrosion processes.
Eleotrochemical studies of the anode grounds of steel 12Х18Н10Т showed
improvement of corrosion deficiency in exploited steels, but over time, this may
lead to an increase in electrical resistance in the anode-coke filling system, which
will cause increased operational and energy expenses.
The studies of steel anode grounding from steel 20 have shown that the
anode earthing switches in their physical condition can continue to operate as
anode grounding, but simultaneously established an increase in electrical resistance
in the system of anode-soil from 2 to 20-40 ohms.
To reduce the electrical resistance of the anode grounds of steel 20, active
substances (activators) were laid. After exploitation of the anode ground with
activators for 23 months, a spectral analysis of anodic grounding samples was
performed that the chemical composition of the steel has not changed and fully
