failure criterion (total elastic energy density). There was confirmed by fractography the
same type of quasi-chipping (spalling) mechanism of specimen failure due to the
transformation of austenite into martensite in the pre-failure zone of deformation.
A method for predicting the residual lifetime of cylindrical SMA elements with
a semieliptical surface crack was proposed. The method is based on solving the system
of equations that describe crack propagation, load parameters and cyclic crack growth
resistance taking into account their statistical scatter and changing the crack front shape
during propagation.
There was developed the damping device based on pseudoelastic SMA,
protected by patents. There was proposed a method for calculating damping device
strength, structural and technical parameters.
Scientific novelty of obtained results
1. There was proposed a number of methods for studying the functional
properties and structural fatigue of shape memory alloys using load-, strain- and
energy-based approaches taking into account temperature, hydrogenation, stress ratio
and variable amplitude.
2. There was found the effect of a significant decrease in the initiation stress for
forward transformation into martensite and failure stress of the hydrogenated alloy in
comparison with non-hydrogenated, as hydrogen affects the phase transformation
process and promotes brittle stratification along the plates of martensitic crystals.
3. There was obtained a set of new experimental data on the change of fatigue
lifetime, cyclic crack growth resistance and functional properties of NiTi alloy
depending on the temperature and stress ratio under constant and variable amplitude
loading.
4. For the first time, there was revealed the effect of partial recovery of functional
properties of nitinol alloy under variable amplitude loading sequence with two blocks
and the mechanism is proposed. This effect occurs at block with low amplitude and
leads to reduction of residual strain that could be the result of residual stresses decrease.
5. There was proposed the criterion of low-cycle fatigue failure of pseudoelastic
