2...5 microns of a round shape were found in the coating structure. The porosity of
the coatings was in the range of 2...5%.
Coatings obtained by PSCDV also have a lamellar structure. However, unlike
HVOF coatings, most of the droplets are practically fused to each other, and the
lamellas are strongly deformed, which indicates that the droplets at the moment of
impact on the sprayed surface were completely melted. VC carbides, extremely small
in size (<500 nm), were found in the coating structure. The porosity of the coatings
did not exceed 0.5%. Such a difference in their structure is caused by a higher
temperature of the plasma (15000°C) than gas-flame jet (2600...2800°C).
The addition of Co powder to the FeCr-VC powder spraying mixture did not
affect the size of VC carbides, but they turned out to be irregular shape. It was found
that the sizes of carbides in the coating structure depend on the chosen spraying
method, which provides a certain temperature to the molten drops. The higher the
temperature of the sprayed droplets the smaller VC carbides are formed in the
coating. Small VC carbides were obtained using the PSCDV method when the
temperature of the droplets was higher than the melting temperature of VC carbides.
So, since the structural phase composition of the formed coatings is the same,
the main factors that affect on their properties are the size of the carbide inclusions
and porosity.
It was found that during friction with a rigidly fixed abrasive, the wear
resistance of coatings increases with the size of VC inclusions. If Co is present in
them, the trend is similar, but wear is greater. Since cobalt does not form carbides,
ductile inclusions based on it are formed in the structure of such a coating.
When tested with non-fixed abrasive, the wear resistance of the coatings
increases with decreasing VC sizes. It was further enhanced with the addition of Co
to the spray powder composition.
By metallographic analysis of the corroded surface, it was found that, unlike an
unmodified alloy, in which, under the corrosive medium influence, sections enriched
in MgZn 2 (Al/MgZn 2 galvanic couple) are dissolved, the modification by SiC
particles of B95 alloy inhibits their dissolution, slowing down corrosion processes,
